The STOPPY B is a versatile electromechanical bollard designed for effective traffic management and access control across a wide range of environments.
The STOPPY B bollard provides a reliable solution for managing vehicle access and enhancing site security in both public and private environments.
It is suitable for a wide range of applications, including commercial premises, urban areas and controlled access zones.
The STOPPY B is available in two main versions to suit different requirements: a 500mm height model with a 115mm diameter, and a larger 700mm height model with a 200mm diameter.
This flexibility allows the bollard to be specified based on the level of security and visual presence required.
Both versions are available in painted steel (RAL 7015) or stainless steel, offering durability and resistance to environmental conditions.
The 700mm model also features an integrated LED light crown, improving visibility and safety in low-light environments.
The bollard uses an electromechanical system with smooth, controlled movement and integrated safety features.
It includes a reversible manual operation function in the event of power failure, ensuring continued usability when required.
Power supply:
230V
Control unit:
Perseo CBE
Shaft height:
500mm
Shaft diameter:
115mm
Shaft thickness:
6mm
Raising time:
7 seconds
Frequency of use:
Semi intensive
Operator type:
Electromechanical
Limit switch:
Reed magnetic sensor
Slowdown:
Yes
Breaking resistance:
60000J
Impact resistance:
7000J
Manual operation:
Reversible with no power
Protection rating:
IP67
Operating temperature:
-20°C to +60°C
Power supply:
230V
Control unit:
Perseo CBE
Shaft height:
700 mm
Shaft diameter:
200mm
Shaft thickness:
6mm
Raising time:
9 seconds
Frequency of use:
Semi intensive
Operator type:
Electromechanical
Limit switch:
Reed magnetic sensor
Slowdown:
Yes
Breaking resistance:
110000J
Impact resistance:
10000J
Manual operation:
Reversible with no power
Protection rating:
IP67
Operating temperature:
-20°C to +60°C
Download the full specification sheet to view detailed dimensions, materials, and technical information for this product.
The STOPPY B electromechanical bollard offers a dependable solution for controlling vehicle access while maintaining flexibility across different environments. Its robust design ensures consistent performance in both security and traffic management applications.
With multiple size and finish options available, the system can be tailored to suit both functional and aesthetic requirements.
Designed with safety and reliability in mind, the bollard provides smooth operation and continued functionality even during power interruptions.
Available in 500mm and 700mm heights to suit different traffic management requirements.
The 700mm version includes an integrated LED light crown for improved visibility.
Electromechanical system with manual override for power loss.
