The HA10000K12 Rising Kerb is a crash-rated road blocker designed to provide maximum hostile vehicle mitigation for critical infrastructure, high-security sites, and environments where uncompromising perimeter protection is essential.
The HA10000K12 is engineered to protect against vehicle-borne threats, providing a robust physical barrier for government facilities, military sites, airports, data centres, utilities, and other critical infrastructure.
Crash tested to PAS 68/K12 standards, the system achieved zero penetration at an impact speed of 80kph while remaining operational following impact, delivering proven protection for the highest security applications.
Powered by a heavy-duty hydraulic drive system with inverter and PLC control, the HA10000K12 is designed for intensive security applications where reliability and performance are critical.
With a 100% duty cycle and a standard operating speed of 5 seconds, the system provides dependable day-to-day operation. An optional emergency fast raise system is also available for applications requiring an accelerated response.
Constructed from high-strength steel, the HA10000K12 is built to withstand demanding operating conditions while delivering long-term perimeter protection.
The road blocker features an anti-skid top surface and integrated safety device monitoring to support safe, reliable operation. Suitable for both indoor and outdoor installations, it is manufactured in the UK for lasting performance.
The HA10000K12 can be integrated with wider security systems, including vehicle detection loops and radar safety systems, allowing it to form part of a comprehensive hostile vehicle mitigation solution.
Available in widths from 2500mm to 4000mm, with a raised height of 1050mm and an axle load capacity of 30 tonnes, the system can be configured to meet the specific requirements of high-security sites.
Crash Rating:
PAS 68 / K12
Impact Rating:
50mph/80kph
Drive System:
Hydraulic
Duty Cycle:
100% Intensive Use
Supply Voltage:
32A, 3 Phase
Standard Operating Speed:
5 Seconds
Emergency Fast Raise:
1.2 Seconds (Optional)
Raised Height:
1050mm
Blocker Depth:
360mm
Available Widths:
2500mm – 4000mm
Axle Load Capacity:
30 Tonnes
Download the full specification sheet to view detailed dimensions, materials, and technical information for this product.
The HA10000K12 Rising Kerb provides the highest level of protection within the HA10000 range, combining PAS 68/K12 crash-tested performance with a heavy-duty hydraulic drive system to deliver reliable protection against high-speed vehicle threats. Designed for intensive use, it offers dependable operation without compromising security.
Manufactured in the UK and engineered for demanding environments, the HA10000K12 combines robust construction, intelligent control, and seamless integration with wider security systems, making it an ideal solution for critical infrastructure and other high-risk locations requiring maximum perimeter protection.
Tested to withstand vehicle impacts at speeds up to 80kph with zero penetration.
Heavy-duty hydraulic drive system with a standard 5-second operating time and optional emergency fast raise.
Engineered for intensive security applications including government facilities, airports, military sites, and data centres.
